M109 (Galaxy)
R/B-band color composite image from the Second Digitized Sky Survey (DSS2), measuring 10 arcminutes across.
Finder chart
Click and drag the chart above to pan around the sky, or use the mouse wheel to zoom.
Click to enlarge.
From Cambridge , M109 is visible in the dawn sky, becoming accessible around 22:31 (EST), when it reaches an altitude of 21° above your north-eastern horizon. It will then reach an altitude of 78° before fading from view as dawn breaks at 05:51.
Begin typing the name of a town near to you, and then select the town from the list of options
which appear below.
|
Name
M109
|
Object type
Galaxy
|
Position
| Right ascension: | 11h57m [4] |
| Declination: | +53°22' [4] |
| Constellation: | Ursa Major |
| Magnitude: | 9.88 (V) [2] 10.48 (B) [2] 7.85 (J) [2] 7.19 (H) [2] 6.94 (K) [2] |
| Angular dimensions: | 8.1 arcmin x 5.6 arcmin |
| Position angle: | Major axis 78.0°E of N |
| Hubble type: | Sbc |
| Distance: | 16.9 Mpc 55.0 Mlyr [1] |
| B-V Color (mag): | 0.60 |
Derived quantities
| Absolute mag (V): | -21.25 |
Visibility from Cambridge
All times shown in Cambridge local time.
